Varsi V60K14 Series Metal Oxide Varistor (MOV), 60VAC, 80VDC, K14 Package, 24W

Features

High Energy Absorption Rating
Industry Standard Package
Wide Operating Range 35 - 1100VAC
High Peak Current Capability (70kA)
UL/CSA/ROHS/ISO9001:2015 Approved
Panel Mount
Screw Terminals

APPLICATION AREAS:

1. Railways and trams: For the protection of electrical equipment, power electronics (IGBT, thyristors...) in systems with alternating, direct or combined AC DC power supply, especially in power supply of AC/DC, DC/AC, DC/DC converters. They may be used in systems with main and auxiliary power supply for example: automatic control and regulation systems, cooling systems, warming systems, ventilation systems, and combination systems (electromechanical, electropneumatic and other systems).

2. Wind powerplants For protection of automatic control and regulation in power electronics (IGTB, tyristors...), as well as the protection of sensitive electronic systems (e. g. AC/DC, DC/AC, DC/DC converters, drive systems) from direct or indirect lightning strikes.

3. Photovoltaic systems For protection of photopanels, automatic control electronics with sensitive electronic components, and DC/AC converters (inverters) from direct or indirect lightning strikes. Depending on the application, both serial and parallel connections are possible. With serial connection the required voltage is achieved. With parallel connection higher current absorption is achieved in the modules.

Specification

Varsi Part Number	V60K14
Operating Voltage AC (50-60Hz)	60V
Operating Voltage DC	100V
Average Power Dissipation	0.6W
Permissable Peak Current	5.5kA
Energy Absorption(2ms)	24W(max)
Tolerance(Vn)	/- 10%
Termination Style	Axial Lead
Weight	7g
Factory Pack Qty	1
ROHS	Yes
UL	Yes
CSA	Yes
