Varsi V385K20 Series Metal Oxide Varistor (MOV), 385VAC, 520VDC, K20 Package

High Energy Absorption Rating
Industry Standard Package
Wide Operating Range 35 - 1100VAC
High Peak Current Capability (70kA)
UL/CSA/ROHS/ISO9001:2015 Approved
Panel Mount
Screw Terminals

APPLICATION AREAS:

1. Railways and trams: For the protection of electrical equipment, power electronics (IGBT, thyristors...) in systems with alternating, direct or combined AC DC power supply, especially in power supply of AC/DC, DC/AC, DC/DC converters. They may be used in systems with main and auxiliary power supply for example: automatic control and regulation systems, cooling systems, warming systems, ventilation systems, and combination systems (electromechanical, electropneumatic and other systems).

2. Wind powerplants For protection of automatic control and regulation in power electronics (IGTB, tyristors...), as well as the protection of sensitive electronic systems (e. g. AC/DC, DC/AC, DC/DC converters, drive systems) from direct or indirect lightning strikes.

3. Photovoltaic systems For protection of photopanels, automatic control electronics with sensitive electronic components, and DC/AC converters (inverters) from direct or indirect lightning strikes. Depending on the application, both serial and parallel connections are possible. With serial connection the required voltage is achieved. With parallel connection higher current absorption is achieved in the modules.

Specification

Varsi Part Number	V385K20
Operating Voltage AC (50-60Hz)	385V
Operating Voltage DC	615V
Average Power Dissipation	1W
Permissable Peak Current	5.5kA
Energy Absorption(2ms)	287W(max)
Tolerance(Vn)	/- 10%
Termination Style	Axial Lead
Weight	7g
Factory Pack Qty	1
ROHS	Yes
UL	Yes
CSA	Yes
